Mini excavators significantly accelerate the operation process, reduce manpower input, and can freely shuttle in narrow areas with their compact size, flexibly performing various operations such as excavation, leveling, and handling, demonstrating excellent maneuverability. lts role is becoming increasingly prominent in small-scale engineering and fine work scenarios.
Mini excavators significantly accelerate the operation process, reduce manpower input, and can freely shuttle in narrow areas with their compact size, flexibly performing various operations such as excavation, leveling, and handling, demonstrating excellent maneuverability. lts role is becoming increasingly prominent in small-scale engineering and fine work scenarios.
| Mini excavator – Type 12 | |||||
| parameter | unit | numerical value | parameter | unit | numerical value |
| Bucket capacity | m³ | 0.025 | Chassis width | mm | 835 |
| Excavation bucket width | mm | 380 | Minimum turning radius | mm | 1290 |
| Excavation height | mm | 2650 | Tail turning radius | mm | 760 |
| Dig deep | mm | 1550 | Seat height | mm | 1500 |
| Max Climb Capability | Degree | 30 | Central rotation | Ketai Hydraulic | |
| Hydraulic oil tank capacity | L | 20 | Walking motor | 4K -310/Yunyang Hydraulic | |
| Oil tank capacity | L | 1.1 | Rotary motor | OMRS-250/Yunyang Hydraulic | |
| Ground clearance | mm | 380 | valve | Jinzhou Shuangling | |
| oil consumption | L/H | 1 | pump | Jiangsu Huaheng Hydraulic | |
| power | KW | 13 – 15 horsepower | Cylinder | Ruihang Technology | |
| weight | KG | 823 | Whole vehicle fuel pipe | Shihai Hydraulic | |
| track width | mm | 180 | Whole vehicle wiring harness | Hezhong Intelligence | |
| Track length | mm | 1250 | Engine model | Bailitong/Science Popularization National II/Science Popularization Euro V/Runtong | |
| hold-all | Common tools | Overall dimensions | 2650MM×850MM×2200MM | ||
Special reminder: different customers will customize the color, configuration, model, appearance and so on according to their own needs. We will make quotations according to the needs of customers.so the quotation will be different. Please understand.
1. Fine Multi Energy
Mini excavators equipped with various accessories can accurately complete fine operations such as excavation and crushing, meeting the needs of landscaping, indoor demolition and other engineering projects
2. Compact and agile
Ultra small size and turning radius enable easy turning and relocation in narrow streets, indoor spaces, and other confined spaces, helping with urban micro renovation and interior decoration.
3. Efficient and energy-saving
Energy saving engine and optimized hydraulic system, ensuring power and low energy consumption, fast operation and cost control.
4. Convenient control
Ergonomic operating room, with reasonable and precise layout of control buttons and levers, easy to use, and comfortable to operate.
(1)Construction site: Used for excavating soil, transporting building materials, quickly completing foundation construction and structural construction, and improving construction efficiency.
(2)Road maintenance: Clean the road surface, rim the plants on both sides of the road. Maintain smooth and safe traffic, especially in urban and rural road maintenance.
(3)Horicultural maintenance: Clearing weeds, loosening soil, and carrying out soil improvement in parks and gardens to maintain a clean green environment.
(4)Waste management: Handling and disposing of various types of waste in garbage dumps and waste treatment centers, keeping the site clean.
